Send Inquiry6ES7-131-4BF50-0AA0-SIEMENS PROGRAMMABLE LOGIC CONTROLLER
Price 7000 INR/ Thousand
MOQ : 2 Pieces
6ES7-131-4BF50-0AA0-SIEMENS PROGRAMMABLE LOGIC CONTROLLER Specification
- Input
- 8 digital inputs
- Sensors Specification
- Supports NAMUR inputs and typical proximity switches
- Processor Speed
- N/A (module is not a CPU)
- Features
- Hot swapping of modules, diagnostics LED, compact design
- Components
- Electronic module, terminal block not included
- Power Source
- Bus powered
- Power Supply
- Bus powered from SIMATIC ET 200S system
- IP Rating
- IP20
- Output
- Not applicable (input module only)
- Usage
- Automation, process control, industrial controllers
- Operating Temperature
- 0C to +60C
- Display Type
- LED status indication for each channel
- Interface
- PROFIBUS DP via ET 200S backplane
- Response Time
- <5 ms
- Product Type
- Programmable Logic Controller Module
- Application
- For use in ET 200S distributed I/O systems
- Rated Voltage
- 24V DC
- Supply Voltage
- 24V DC
- Size
- Standard ET 200S module size
- Dimension (L*W*H)
- 81 mm x 15 mm x 52 mm
- Function
- I/O Module for input expansion on SIMATIC S7-300 systems
- Color
- Grey
- Weight
- Approximately 70 g
- Capacity
- 8 channels
- Current Rating
- 6 mA per channel
- Thickness
- 15 mm (approx.)
- Frequency
- Input scanning up to 500 Hz
- Mounting Type
- DIN rail via ET 200S base units
- Module Type
- Digital input module (DI 8x24VDC ST)
- Channel to Channel Isolation
- No (common reference), channel to backplane: yes
- Relative Humidity (Operation)
- 5% to 95%, non-condensing
- Compatible Systems
- SIMATIC ET 200S, S7-300
- Isolation Voltage
- 500 V between channels and backplane
- Hot Swap Capability
- Yes
- Max Permissible Humidity
- 95% RH, non-condensing
- Storage Temperature
- -40°C to +70°C
- Environmental Protection
- IP20, for panel installation
- Number of Modules per Station
- Up to 64 per ET 200S station
- Power Dissipation
- approx. 0.9 W
- Wire Connection
- Screw or spring-loaded terminals (with terminal module)
About 6ES7-131-4BF50-0AA0-SIEMENS PROGRAMMABLE LOGIC CONTROLLER
Capitalise on the remarkable efficiency and exclusive design of the 6ES7-131-4BF50-0AA0-SIEMENS Digital Input Module. This splendiferous module for SIMATIC ET 200S offers 8x24VDC digital inputs in a robust, grey housing suited for seamless DIN rail mounting. Its lustrous, compact structure allows hot swapping for minimal downtime. Customizable connection options ensure flexibility, while its operation is optimised for automation, process control, and demanding industrial controllers. Distinguished by Siemens' engineering heritage, this module is remarked for its reliability, plant versatility, and diagnostic LED indications. Experience exceptional input expansion and superior plant integration.
Highlighting Splendid Features and Applications
The 6ES7-131-4BF50-0AA0-SIEMENS module boasts a suite of special features such as hot swapping, diagnostic LEDs for swift issue identification, and robust IP20-rated panel installation suitability. Its compact design enables up to 64 modules per ET 200S station, supporting diverse plant automation needs. Exclusively suited for industrial controllers and process plants, this module offers customizable input configurations, ensuring seamless integration. Experience splendiferous performance in harsh environments where high ambient humidity and temperature resilience are essential.
Supply Ability, Delivery Time, and Commercial Terms
With ample supply capacity, the 6ES7-131-4BF50-0AA0 is ready to be handed over with competitive delivery timelines tailored to project demands. Clients seeking quotations will find the outlay aligned with Siemens' commitment to quality and value. Payment terms are designed for flexibility and convenience, ensuring reliable procurement and project continuity. Whether for large-scale automation projects or incremental plant upgrades, this input module guarantees dependable delivery and commercial clarity for global clients.
Highlighting Splendid Features and Applications
The 6ES7-131-4BF50-0AA0-SIEMENS module boasts a suite of special features such as hot swapping, diagnostic LEDs for swift issue identification, and robust IP20-rated panel installation suitability. Its compact design enables up to 64 modules per ET 200S station, supporting diverse plant automation needs. Exclusively suited for industrial controllers and process plants, this module offers customizable input configurations, ensuring seamless integration. Experience splendiferous performance in harsh environments where high ambient humidity and temperature resilience are essential.
Supply Ability, Delivery Time, and Commercial Terms
With ample supply capacity, the 6ES7-131-4BF50-0AA0 is ready to be handed over with competitive delivery timelines tailored to project demands. Clients seeking quotations will find the outlay aligned with Siemens' commitment to quality and value. Payment terms are designed for flexibility and convenience, ensuring reliable procurement and project continuity. Whether for large-scale automation projects or incremental plant upgrades, this input module guarantees dependable delivery and commercial clarity for global clients.
| Electronics module for ET 200S, 8 DI source input 24 V DC, 15 mm width, 1 unit per packing unit |
| EAN | 4025515075585 | ||
| UPC | Not available | ||
| Commodity Code | 85389091 | ||
| LKZ_FDB/ CatalogID | ST76 | ||
| Product Group | 2301 | ||
| Group Code | R151 | ||
| Country of origin | Germany | ||
| Compliance with the substance restrictions according to RoHS directive | Since: 31.03.2008 | ||
| Product class | A: Standard product which is a stock item could be returned within the returns guidelines/period. | ||
| WEEE (2012/19/EU) Take-Back Obligation | Yes | ||
| REACH Art. 33 Duty to inform according to the current list of candidates |
|
FAQ's of 6ES7-131-4BF50-0AA0-SIEMENS PROGRAMMABLE LOGIC CONTROLLER:
Q: How does the 6ES7-131-4BF50-0AA0-SIEMENS module contribute to automation systems?
A: This module expands input capacity for SIMATIC ET 200S and S7-300 systems, allowing seamless capture of digital signals from field devices, thus enhancing process control and plant automation.Q: What special features distinguish this digital input module for industrial use?
A: It features hot swapping, a compact footprint, diagnostic LED status for each channel, high humidity and temperature tolerance, and flexible terminal options-customizable for numerous plant scenarios.Q: Where can this module be installed and operated reliably?
A: It is specifically engineered for panel installation in industrial environments, offering IP20 protection, robust performance in high humidity (up to 95% non-condensing), and adherence to rigorous storage and operation temperatures.Q: What is the process for connecting field wiring to this module?
A: Field wiring can be effortlessly connected via screw or spring-loaded terminals (with the terminal module), ensuring swift and secure installation on DIN rails via ET 200S base units.Q: When is hot swapping of the input module beneficial for plant operations?
A: Hot swapping enables replacement or addition of modules during system operation without causing system downtime, making it invaluable for continuous-run automation environments.Q: What are the main usage benefits offered by this Siemens input module?
A: Key benefits include expanded input capabilities, swift diagnostics, dependable operation under harsh conditions, space-saving modularity, and streamlined plant upgrade processes.
