Send Inquiry6ES7-223-1BL22-0XA0-SIEMENS PROGRAMMABLE LOGIC CONTROLLER
Price 8000 INR/ Thousand
MOQ : 2 Pieces
6ES7-223-1BL22-0XA0-SIEMENS PROGRAMMABLE LOGIC CONTROLLER Specification
- Power Supply
- External, 24V DC
- IP Rating
- IP20 (for control cabinet installation)
- Output
- 16 digital outputs (relay, 2A per channel)
- Features
- Expandable, high-speed processing, relay outputs, compact design
- Operating Temperature
- 0C to +55C
- Interface
- RS-485 communication (MPI/PROFIBUS supported)
- Display Type
- LED status indicators
- Sensors Specification
- Compatible with digital sensors (24V DC logic)
- Resolution
- Digital I/O - discrete states
- Usage
- Industrial automation, machine control, process control
- Processor Speed
- Fast processing cycle (typical for S7-200 series)
- Power Source
- External DC supply
- Input
- 16 digital inputs (24 V DC, sink/source)
- Components
- Integrated CPU, input/output terminals, relay outputs
- Response Time
- Input response time: < 3 ms
- Product Type
- Programmable Logic Controller (PLC)
- Application
- Factory automation, machinery, production line control
- Rated Voltage
- 24V DC
- Supply Voltage
- 20.4 to 28.8V DC
- Size
- Compact modular
- Dimension (L*W*H)
- 120mm x 80mm x 70mm (approx.)
- Function
- Programmable Logic Controller (PLC) for automation and control applications
- Color
- Gray
- Weight
- Approximately 500g
- Current Rating
- Input: max. 5mA per channel; Output: 2A per output relay
- Capacity
- 32 I/O channels (16DI/16DO)
- Thickness
- 70mm (device depth)
- Frequency
- 47 Hz to 63 Hz
- Type of Outputs
- Relay
- Analog I/O
- Not supported on this module
- Cycle Time
- Typically 0.37 ms per 1 K instructions
- Storage Temperature
- -40°C to +70°C
- Model Number
- 6ES7-223-1BL22-0XA0
- Relative Humidity
- 5% to 95% (non-condensing)
- Status Indication
- Integrated LED for input/output and module status
- Number of Modules per Rack
- Up to 8 modules
- Series
- SIMATIC S7-200
- Programming Language
- LAD, FBD, STL (via Step 7 Micro/WIN)
- Maximum Expansion Modules
- Supports multiple expansion modules
- Mounting Type
- DIN Rail mounting
About 6ES7-223-1BL22-0XA0-SIEMENS PROGRAMMABLE LOGIC CONTROLLER
SIMATIC S7-200, DIGITAL I/O EM 223, FOR S7-22X CPU ONLY, 16 DI 24 V DC, SINK/SOURCE, 16DO 24V DC, 0.75A/POINT,SOURCE| EAN | 4025515162315 | |
| UPC | 662643204766 | |
| Commodity Code | 85389091 | |
| LKZ_FDB/ CatalogID | ST9-E5 | |
| Product Group | 4557 | |
| Group Code | R111 | |
| Country of origin | United States of America | |
| Compliance with the substance restrictions according to RoHS directive | Product is not RoHS-compliant | |
| Product class | D: products made to order / customer's specifications, requiring engineering services, which cannot be re-used or utilized (design to customer) | |
| WEEE (2012/19/EU) Take-Back Obligation | - | |
| REACH Art. 33 Duty to inform according to the current list of candidates |
|
Versatile Industrial Automation
Engineered for demanding environments, the S7-200 series PLC offers reliable control for a wide range of factory and machine automation tasks. Its compact modular design, expandable architecture, and robust relay outputs ensure flexibility for different system requirements.
Seamless Programming and Integration
Programming and integration are straightforward with support for LAD, FBD, and STL languages via STEP 7 Micro/WIN. The built-in RS-485 interface facilitates communication over MPI or PROFIBUS, allowing seamless connection with other automation components.
Efficient and Reliable Performance
Enjoy rapid cycle times of approximately 0.37 ms per 1K instructions and swift input response times under 3 ms. Integrated LED indicators provide clear feedback on input and output status, helping operators monitor and troubleshoot operations effectively.
FAQ's of 6ES7-223-1BL22-0XA0-SIEMENS PROGRAMMABLE LOGIC CONTROLLER:
Q: How can I expand the capabilities of the 6ES7-223-1BL22-0XA0 SIMATIC S7-200 PLC?
A: You can expand the PLC's I/O capacity by adding multiple compatible expansion modules. The system supports up to eight modules per rack, allowing you to tailor configurations to your specific automation needs.Q: What programming languages are supported and how do I program this controller?
A: The controller supports LAD (Ladder Diagram), FBD (Function Block Diagram), and STL (Statement List) programming languages. Programming is performed using STEP 7 Micro/WIN software, offering a user-friendly environment for configuration and troubleshooting.Q: Where should the 6ES7-223-1BL22-0XA0 module be installed?
A: The module is designed for DIN rail mounting inside a control cabinet. Its IP20 rating ensures reliable protection and performance in industrial settings, provided it is installed in a suitable enclosure.Q: What are the power supply requirements and process for connecting power?
A: This PLC requires an external 24V DC power supply, with an acceptable voltage range between 20.4V and 28.8V DC. Connect the supply to the designated input terminals, ensuring the system is correctly polarized and meets the power ratings.Q: Which sensors and devices are compatible with this PLC module?
A: The 6ES7-223-1BL22-0XA0 supports digital sensors operating at 24V DC. Inputs are compatible with both sink and source connection types, providing flexibility for various industrial sensors and switches.Q: What are the main benefits of using this SIEMENS PLC in industrial automation?
A: Key benefits include fast processing speeds, expandability, robust relay outputs, integrated LED diagnostics, and compact design, all of which combine to deliver efficient, reliable automation control and easy system scalability.
