6ES7 350 -1AH03-0AE0

Price 18000 INR/ Thousand

Get a Price/Quote

MOQ : 2 Pieces

6ES7 350 -1AH03-0AE0 Specification

Components
Electronic module, terminal block

Response Time
1 ms signal delay

Interface
Backplane bus interface

Usage
For digital control and automation systems

Sensors Specification
Supports proximity switches, encoders

Features
Fast counting, direct encoder pulse evaluation, hot swapping

Operating Temperature
0C to 60C

Power Source
Backplane power

Input
6 digital inputs (2 channels)

Output
6 digital outputs (2 channels)

Resolution
32-bit counter resolution

Display Type
LED indicators for status display

Power Supply
Via backplane bus

IP Rating
IP20

Product Type
Counter Module

Application
Industrial automation, S7-300 PLC systems

Rated Voltage
24 V DC

Supply Voltage
24 V DC

Size
125 mm x 40 mm x 120 mm

Dimension (L*W*H)
125 x 40 x 120 mm

Function
Counter Module for S7-300 Automationsystem

Color
Gray

Weight
Approx. 200 g

Current Rating
Max 0.5 A per channel

Thickness
Approx. 125 mm

Capacity
2 counting channels, 6 inputs

Frequency
Max. counting frequency 60 kHz

Relative Humidity
5% to 95% (non-condensing)

Number of Modules per Rack
Up to 8 modules

Environmental Protection
RoHS compliant

Signal Type
24 V DC, pulse/direction, up/down

Shock/Vibration
Meets IEC 61131-2 standards

Mounting Type
DIN Rail mounting (S7-300 rack)

Model Number
6ES7 350-1AH03-0AE0

Compatible Systems
SIMATIC S7-300/ET 200M

About 6ES7 350 -1AH03-0AE0

SIMATIC S7-300, Counter module FM 350-2, 8 channels, 20 kHz, 24 V encoder for counting, frequency measurement, speed measurement, period duration measurement, dosing incl. configuration package and electronic documentation on CD-ROM

EAN

4025515076445

UPC

662643401523

Commodity Code

85389091

LKZ_FDB/ CatalogID

ST73

Product Group

X07X

Group Code

R151

Country of origin

Germany

Compliance with the substance restrictions according to RoHS directive

Since: 25.11.2009

Product class

A: Standard product which is a stock item could be returned within the returns guidelines/period.

WEEE (2012/19/EU) Take-Back Obligation

Yes

REACH Art. 33 Duty to inform according to the current list of candidates

Lead CAS-No. 7439-92-1 > 0, 1 % (w / w)

Lead monoxide (lead ... CAS-No. 1317-36-8 > 0, 1 % (w / w)

4,4'-isopropylidened... CAS-No. 80-05-7 > 0, 1 % (w / w)

Perfluorobutane sulfonic ... > 0, 1 % (w / w)

Precision and Flexibility for Automation Systems

The 6ES7 350-1AH03-0AE0 counter module enhances process control by enabling fast and accurate counting functions directly within S7-300 and ET 200M systems. Its robust processing capabilities, compatibility with various sensors, and dual-channel architecture make it exceptionally suited for complex automation tasks. Integration with SIMATIC S7-300 ensures seamless operation and scalability in industrial environments.

Reliable Performance in Demanding Environments

Engineered to thrive in tough industrial conditions, this module tolerates a wide temperature range (0C to 60C) and up to 95% non-condensing relative humidity. Its compliance with IEC 61131-2 shock and vibration standards, along with IP20 protection and RoHS certification, assures lasting durability and safe usage in rigorous automation settings.

FAQ's of 6ES7 350 -1AH03-0AE0:

Q: How do I mount the 6ES7 350-1AH03-0AE0 counter module in my automation setup?

A: The 6ES7 350-1AH03-0AE0 is designed for DIN rail mounting within an S7-300 rack. Simply slot the module onto the backplane bus of your SIMATIC S7-300 or ET 200M system to integrate it with other system components.

Q: What types of signals and sensors are compatible with this counter module?

A: This module supports 24 V DC pulse/direction and up/down signals. It is compatible with encoders and proximity switches, allowing it to interface efficiently with a wide variety of industrial sensors.

Q: When should I use the 6ES7 350-1AH03-0AE0 in my automation project?

A: Use this counter module whenever precise, high-frequency digital counting or direct encoder pulse evaluation is required in SIMATIC S7-300 or ET 200M automation solutions, such as in manufacturing or materials handling applications.

Q: Where can the module be installed for optimal performance and protection?

A: Install the module in a protected, well-ventilated control cabinet with a standard DIN rail. Ensure environmental conditions stay within 0C to 60C, 5% to 95% non-condensing humidity, and that dust or moisture exposure is minimal (IP20 rated).

Q: What process steps are involved in commissioning the module?

A: Commissioning involves securing the module onto the S7-300 rack, connecting required sensors and actuators, verifying 24 V DC power supply through the backplane, and configuring channel parameters with the automation software before initiating operation.

Q: How does using this counter module benefit my automation system?

A: The 6ES7 350-1AH03-0AE0 delivers fast, reliable counting-even at up to 60 kHz-with a 1 ms response time and 32-bit resolution, supporting efficient, precise process control. Its hot swappable design minimizes downtime during maintenance or upgrades.
