PACSystems RX3i Universal Power Supply

Name: PACSystems RX3i Universal Power Supply
Brand: BRT ENTERPRISES
Price: 75554.0 INR
Availability: InStock

Price 75554.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Kilograms

PACSystems RX3i Universal Power Supply Specification

Usage
Load-sharing and redundancy applications

Power Supply
AC or DC Multipurpose

Charging Voltage
40 Statampere (sA)

Sensors Specification
Internal thermal sensors for overtemperature protection

IP Rating
IP20

Input
70 Watts maximum with full load

Interface
RX3i Universal Backplane (PCIe/PCI interface)

Output
40 Watts total; +5.1 VDC (30W), +3.3 VDC (30W), +24 VDC (40W)

Operating Temperature
60 Celsius (oC)

Thermal Conductivity
Standard convection cooling Watt/Centimeter/C (W/(cm.C)

Features
Load sharing, redundancy (up to 4 units), internal protection

Response Time
20 Seconds

Power Source
AC (85 264 VAC) or DC (100 300 VDC)

Processor Speed
N/A (Module is a power supply, not a CPU)

Display Type
LED Displays

Resolution
N/A (This is a non-digital display component)

Components
Internal short-circuit & overvoltage protection, 4 status LEDs

Product Type
PACSystems RX3i Power Supply Module

Power Rating
40 Watts (Combined maximum output)

Application
Industrial automation; redundant RX3i backplane power

Supply Voltage
264 Volt (v)

Size
Standard RX3i module (double-wide)

Dimension (L*W*H)
139 x 58.4 x 135 Millimeter (mm)

Function
Multipurpose 40-Watt Power Supply

Color
Standard industrial gray/black

Weight
1.2 Kilograms (kg)

Warranty
1 year

Rated Voltage
240 Volt (V)

Usage & Applications
PACSystems RX3i backplane power for I/O and CPU modules

Cable Type
Standard insulated field wiring (14 22 AWG)

Phase
Single-Phase (for AC operation)

Conductor
Copper (AWG #14 to #22 recommended for field wiring)

Material
Industrial-grade polycarbonate and metal

Rated Current
70 Watt (w)

Thickness
2 Gauge

Current Rating
5.1VDC: up to 6A | 3.3VDC: up to 9A | 24VDC Relay: up to 1.6A

Frequency
47 to 63 Hertz (HZ)

PACSystems RX3i Universal Power Supply Trade Information

Minimum Order Quantity
1 Kilograms

Delivery Time
10 Days

About PACSystems RX3i Universal Power Supply

The

IC695PSA140

is a 40-Watt multipurpose power supply module for the Emerson (formerly GE Fanuc) PACSystems RX3i controller series. It is specifically designed to provide reliable power to the backplane in industrial automation environments, supporting both load-sharing and redundancy configurations.

Advanced Reliability for Industrial Automation

Engineered for mission-critical applications, the PACSystems RX3i Universal Power Supply delivers reliable, consistent power to automation systems. Its redundant capability and load-sharing design ensure uninterrupted operation, making it ideal for processes demanding high uptime. The module easily integrates into RX3i backplanes with both AC and DC power sources, accommodating industry-standard installation requirements.

Comprehensive Safety and Protection Features

This power supply incorporates multiple layers of protection, including internal thermal sensors, short-circuit, and overvoltage safeguards. The four LED indicators on the front panel provide real-time status updates on power, faults, temperature, and overload conditions, enabling quick diagnostics and maintenance. Designed to keep automation systems secure and efficient, it minimizes the risk of costly downtime.

FAQ's of PACSystems RX3i Universal Power Supply:

Q: How does the PACSystems RX3i Universal Power Supply contribute to system redundancy and reliability?

A: This power supply supports redundancy by allowing up to four units to operate in parallel for load-sharing and backup. If one unit fails, others maintain uninterrupted power, enhancing overall system reliability in critical industrial environments.

Q: What applications is this power supply best suited for?

A: The RX3i Universal Power Supply is specifically designed for industrial automation, providing backplane power for RX3i CPU and I/O modules. It is commonly used in processes requiring high uptime, such as manufacturing, utilities, and process control.

Q: Where should this module be installed within the control system?

A: Install the unit directly into the RX3i universal backplane, occupying a standard double-wide slot. Its design matches typical RX3i system layouts, ensuring seamless integration with existing hardware and field wiring.

Q: What are the key features that facilitate safe operation of this power supply?

A: Key safety features include internal thermal sensors for overtemperature protection, short-circuit and overvoltage safeguards, and four status LEDs for immediate fault and performance awareness. These elements help prevent damage and ensure safe operation.

Q: How can I monitor the status and health of the power supply in real time?

A: The front panel features four dedicated LED indicators for power, power supply fault, over temperature, and overload. These LEDs provide quick visual feedback so operators can monitor the unit's condition without external tools.

Q: What wiring and field connections does the module support?

A: The power supply is compatible with standard insulated copper field wiring, 14 to 22 AWG. This supports common industrial installation practices and ensures a secure, reliable connection to your automation platform.
